Ad Number: | 863 |
Year: | 2024 - Appx 8 Weeks to Completion |
Model: | 2024 Self Propelled Spud Barge |
Length: | 50' |
Beam: | 12' |
Light Draft / Max Draft /Light Ship Weight/: | 4' |
Propulsion/ Props/: | Twin Yamaha 115 XL shaft with all rigging and install (hydro steering, stainless props, batteries, controls, cables, harness, gauges, etc) Spud ring lifting collars |
Your Price: | $219,880.00 |
Boat Location: | Florida |
Aluminum console, dual engine brackets, rigging pipe chase 18" Structural crane pedestal and 6" elevated HPU platform Tiger 1069 Crane- 11,000lb max cap and 29ft max reach BravePro powerpack with 20 HP Honda Engine | |
Contact Us: | Email Us |
Call Us: | Bob - 954.224.2628 |
50x12x4 Raked Bow Barge with following features:
1/4" Plate, 3x3x1/4" framing on 24" centers, 6 cleats, Flush manway, 2 coat epoxy paint system on exterior
Internal spudwell 8"
6" sch80 steel spuds 20ft long with hats and pins
Antifouling on underwater hull including 3rd coat of epoxy Bolt on plate anodes
Aluminum console, dual engine brackets, rigging pipe chase
18" Structural crane pedestal and 6" elevated HPU platform
Tiger 1069 Crane- 11,000lb max cap and 29ft max reach
BravePro powerpack with 20 HP Honda Engine
(2)Yamaha 115 XL shaft with all rigging and install (hydro steering, stainless
props, batteries, controls, cables, harness, gauges, etc) Spud ring lifting collars
